The AIDA Imaging UHD-X3L 4K HDMI POV Camera is a professional micro POV camera with 3X optical zoom capabilities. Ideal for wide-angle viewing, the UHD-X3L is robust in its features, integrating 4K UHD Progressive CMOS sensors with a digital image processor to maintain sharpness in quality without compromise. The UHD-X3L is great under low light conditions with its motion-compensated temporal noise reduction filter.
It is an ultra-compact field production camera suitable for web-conferencing, sports, auto racing, surveillance, medical, broadcasting, live production, education, house of worship, and other applications. Designed for versatility, durability, and cost-effectiveness for smooth integration into any broadcast, professional, or corporate AV environment.
- 4K UHD 1/2.5 Progressive Scan CMOS sensor captures sharp and vivid UHD video even under very low light conditions
- 3X optical zoom features a 25~78 wide angle of view
- Built-in zoom lens offers zoom, focus, and iris control
- Advanced digital imaging processor provides vivid and detailed images by utilizing Dynamic Range, Auto White Balance, and Noise Reduction
- Superb motion-compensated temporal noise reduction filter for motion video without blurring
- OSD control breakout cable with power input and RS-485 for remote communication
- Perfectly suited for huddle rooms, broadcast, pro audio/video, and security
- Versatile, compact, and rugged design
Video
Image Sensor | 1/2.5" Progressive CMOS |
Sensor Size | Diagonal 7.20mm |
Effective Pixels | Horizontal: 3840, Vertical: 2202 |
Pixel Size | 1.62 μm (H) x 1.62 μm (V) |
Resolution | 2160p: 3840 x 2160 1080p / 1080i : 1920 x 1080 720p : 1280 x 720 |
Resolution/Rate | 4K2160p: 30 / 29.97 / 25 / 24 1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 1080i: 60 / 59.94 / 50 720p: 60 / 59.94 / 50 |
Output | HDMI 1.4 |
Color Space | 4:2:2 (YCbCr) 10 bit |
Function
White Balance | AWB / AE / AF |
Exposure | Full Auto, Bright, Shutter Priority, Iris Priority, Manual |
Other | WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection |
Lens
Lens | 3X Optical Zoom Lens, 3.85mm/78° (Wide) ~ 13.4mm/25° (Tele) |
Standard
SMPTE | SMPTE 292M, SMPTE 424M, SMPTE 2081-10 |
Physical
Camera Control | RS-485, OSD Button |
Operation Temp | 32°F - 104°F |
Dimension | 48mm x 48mm x 83.09mm / 1.89" x 1.89" x 3.27" |
Weight | 140g / 0.30lbs |
Power | 12 VDC (+9 - +15VDC) |
- AIDA Imaging UHD-X3L 4K HDMI POV Camera
- OSD Control Breakout Cable
- Power Cord with 3 Universal Plug Adapters
- Remote Control
- Hex Wrench
- Limited 1-Year Warranty
