AIDA Imaging Full HD NDI®|HX / IP Weatherproof POV Camera

AIDA Imaging Full HD NDI®|HX / IP Weatherproof POV Camera
9420 E DoubleTree Ranch Rd #107
9420 E DoubleTree Ranch Rd #107
Scottsdale AZ 85258
United States
The AIDA Imaging Full HD NDI®|HX / IP Weatherproof POV Camera is the harmonious blend of NDI|HX and outdoor streaming. Its IP67 rating keeps the camera dust and moisture free, with the ability to submerge the camera up to 1m for 30 minutes. Enjoy NDI|HX with AIDA’s renowned form factor, whether it be indoors or outdoors.
It brings IP and NDI output into an ultracompact form for POV streaming applications in broadcast, education, medical, live production, and other fields. This model features weatherproofing, so it can be easily integrated into an outdoor environment. It outputs variable frame rate IP streaming via RTSP/RTMP and/or NDI|HX with up to 1080p60 resolution.
- Full-HD 1/3” Progressive Scan CMOS sensor capable of 1080 60p NDI®|HX Video
- Accessible Web UI to stream directly to social media platforms and control image parameters over IP
- Versatile design with top and bottom tripod mounts for unique shot creation
- CS mount lens allows for extra clarity over other types of lenses
- The weatherproof rating allows for extra protection against environmental elements
- Small form factor and rugged design make all video streaming applications possible
- Perfectly suited for outdoor shots any new or existing NDI®|HX setup
Video
Image Sensor | 1/3” Progressive CMOS |
Sensor Size | 5.346mm x 3.003mm (16.9) |
Effective Pixels | Horizontal: 1920, Vertical: 1080 |
Pixel Size | 2.75 μm (H) x 2.75 μm (V) |
Resolution | 1080p, 1080i, 720p |
Resolution Rate | 1080 60p/59.94/50p/30p/29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p |
Output | IP (NDI|HX/SRT/RTMP/RTSP) |
Color Space | 4:2:2 (YCbCr) 10bit |
Min Illumination | 0.2Lux (day), 0.1Lux (Night) |
White Balance | Auto & Manual (9000 - 11,000 K) |
Lens
Lens | C/CS Mount (Default 4mm HD Lens with CAP) |
Standard
IP Protocol | UDP|IP, RTSP|RTMP, SRT, NDI|HX |
Physical
Camera Control Protocol | VISCA Over IP |
Operation Temp | 32 °F - 104 °F |
Dimension | 78mm x 41mm x 41mm / 3.07” x 1.61” x 1.61” (with default WP cap) |
Weight | 454g / 1 lb (with default WP cap) |
Power | 12VDC (+9 - +15VDC) (PoE Adapter Included) |
- AIDA Imaging Full HD NDI HX / IP Streaming Weatherproof POV Camera
- PoE/Ethernet Dongle Adapter (10')
- 12 VDC Power Supply with Plug Adapter Kit
- C-Mount Cap Adapter
- Sensor Cap
- Limited 2-Year Warranty
