AIDA Imaging GEN3G-200 -SDI/HDMI Full HD Genlock Camera
AIDA Imaging GEN3G-200 -SDI/HDMI Full HD Genlock Camera
9420 E DoubleTree Ranch Rd #107
9420 E DoubleTree Ranch Rd #107
Scottsdale AZ 85258
United States
Hurry and Save
- FREE Shipping for orders $150 above
- Add $25 for 2-day expedited shipping
- Ask about our Refer a Friend Program!
Got A Question? - Ask Our Team
AIDA Imaging GEN3G-200: Your Ultimate SDI/HDMI Full HD Genlock Camera Solution
The AIDA Imaging GEN3G-200-SDI/HDMI Full HD Genlock Camera is the ultimate solution for a wide range of applications, including web-conferencing, sports, surveillance, medical, broadcasting, live production, and house of worship. This compact 3G-SDI Broadcast Camera delivers crystal-clear and vibrant HD video, making it a versatile choice for various HD video needs. Its rugged yet compact design ensures flexibility in deployment. Additionally, the camera boasts Self-Adaptive Genlock Tri-level Sync, customizable image settings through a built-in OSD, and an interchangeable lens design, allowing compatibility with auto-iris CS and C mount lenses. It also features audio input capable of relaying embedded audio via SDI & HDMI, making the AIDA GEN3G-200 an essential tool for a wide array of video production workflows.
Key features:
- Built-in true Genlock capability: This allows the camera to be synchronized with other cameras and devices in a multi-camera setup, which is essential for professional VR filmmaking and 360 video productions.
- Interchangeable lens design: This makes the camera compatible with a wide range of auto-iris CS and C mount lenses, giving users flexibility to choose the right lens for their specific needs.
- Built-in OSD controls: This feature lets you personalize the camera's image settings, like adjusting the colors, brightness, and how fast the shutter opens and closes, so you can get the perfect shot.
- Compact and rugged design: The camera is compact and lightweight, so you can effortlessly carry it around and use it in different places.
- Self-adaptive Genlock Tri-level Sync: This ensures that the camera stays synchronized with other devices even if the sync signal is unstable.
- Embedded audio: The camera can relay embedded audio via SDI and HDMI, which eliminates the need for external audio cables.
- Wide dynamic range: The camera captures a wider range of brightness levels than traditional cameras, which can be beneficial for shooting in low-light or high-contrast environments.
- Noise reduction: The camera's noise reduction algorithms help to produce clean and clear images, even in challenging lighting conditions.
- Full HD Progressive Scan sensor captures sharp and vivid color under different light conditions
- Advanced digital imaging processor provides vivid and detailed images by utilizing WDR, White Balance, and Noise reduction
- Mohon-Compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur
- Tri-level sync Genlock synchronizes GEN3 cameras and other system components for seamless vertical interval switching between sources
- 3G/HD-SDI & HDMI seamless video performance
- Compatible with other industry-leading products, conforming with SMPTE 424M / 292M standard
- Self-AdapPve ResoluPon Feature captures your reference feed instantly
- Black Level Set-up provides a better color transition from digital to analog
- Auto White balance and shutter speed provide optimized performance in a variety of situations
- Interchangeable lens design making it compatible with auto-iris CS and C mount lenses
- Flawlessly relays embedded audio via SDI & HDMI
- Built-in OSD controls for customizable image settings
- Versatile, compact, and rugged design
Video
| Image Sensor | 1/3 inch Progressive CMOS |
| Sensor Size | 5.346mm x 3.003mm (16:9) |
| Effective Pixels | Horizontal: 1920, Vertical: 1080 |
| Pixel Size | 2.75 µm x 2.75 µm |
| Resolution | 1080p & 1080i: 1920 x 1080 720p & 720i: 1280 x 720 |
| Resolution/Rate | 1080 60p/59.94p/50p/30p/29.97p/ 25p 1080 60i/59.94i/50i 720 60p/59.94p/50p/30p/25p |
| Output | HD-SDI/3G-SDI (1 BNC) HDMI 1.3a |
| Color Space | 4:2:2 (YCbCr) 10bit |
| Min. Illumination | 0.2Lux (Day), 0.1Lux (Night), 0.005Lux (Slow Shutter ON) |
| White Balance | Auto & Manual (19,000 K - 11,000 K) |
Lens
| Lens | C/CS Mount (Default 3.6mm HD Lens) |
Audio
| Audio Input | 3.5mm Analog Audio Input through I/O Cable |
| Sample Rate | 16 / 24 / 32 Bits |
Standard
| SMPTE | SMPTE 292M, SMPTE 424M |
Synchronization
| Genlock | External Tri-Level Input |
Physical
| Camera Control | RS-485, OSD Button |
| Operation Temp | 32° F - 104° F |
| Dimension | 49mm x 49m x 71mm / 1.92” x 1.92” x 2.79” (With default 3.6mm Lens) |
| Weight | 180g / 0.39Lbs (With default 3.6mm Lens) |
| Power | 6W at 12VDC (+9 - +15VDC) |
- AIDA Imaging 3G-SDI/HDMI Full HD Genlock Camera with 4mm Fixed Lens
- I/O Breakout Cable
- 12 VDC Power Supply
- International Power Adapter Kit
- Limited Warranty
