Yealink W76P DECT Phone System

Yealink W76P: A Scalable, Secure, and Mobile DECT Phone System for SMBs

The Yealink W76P DECT Phone System stands out as an ideal solution for small to medium-sized businesses prioritizing clear communication, mobility, and scalability. This robust system supports up to 10 handsets and 10 SIP accounts, facilitating flexible communication dynamics within your organization. With DECT technology, it enables extended wireless range, ensuring that conversations can continue uninterrupted even when moving across large spaces. The system also boasts superior HD audio quality with noise reduction capabilities, making every call crisp and clear, even in bustling environments.

Management is simplified through features like Yealink's Redirection and Provisioning Service, and security is fortified with TLS and SRTP encryption. The Yealink W76P also integrates seamlessly with Microsoft Teams, adding to its versatility and making it a comprehensive communication solution for forward-thinking businesses.

More Details:

• Scalability: Accommodates up to 10 Yealink W56H DECT handsets and 10 SIP accounts, providing ample growth potential for your business communications.
• Enhanced Mobility: Features DECT technology with a wireless range of up to 984ft outdoors, plus Bluetooth 5.1 support for seamless hands-free calling and headset connectivity.
• Superior Audio Quality: Ensures clear calls with HD audio and a noise reduction system, even in noisy environments.
• Streamlined Management: Utilizes Yealink's Redirection and Provisioning Service (RPS) and Boot mechanism for efficient setup and maintenance.
• Robust Security: Employs TLS & SRTP encryption protocols to protect your communications from interception and tampering.
• Extended Coverage: Optional repeaters can be added to expand network coverage, accommodating larger operational areas.
• Microsoft Teams Integration: Supports Microsoft SIP Gateway, allowing for smooth integration with Microsoft Teams to enhance collaborative efforts.
• Durable and Reliable: IP54 rated for dust and water resistance, ensuring durability in various environments and conditions.
• Convenient Upgrades: Offers Over-the-Air (OTA) updates to keep the system current without manual interventions.
• Quick Charging: Provides quick charging capabilities, reducing downtime and enhancing productivity.

Applications:

• Small to Medium-Sized Businesses: Provides scalable and efficient communication solutions that grow with the business.
• Retail Environments: Enhances customer service with wireless mobility, allowing staff to communicate from anywhere in the store.
• Warehouses and Large Offices: Offers extensive coverage with the ability to add repeaters, ideal for maintaining clear communication across large spaces.
• Healthcare Facilities: Supports hands-free operation and robust security features, essential for fast-paced, privacy-sensitive environments.
• Hospitality Industry: Improves staff coordination and guest services in hotels and resorts through seamless integration with mobile and headset connectivity.
• Educational Institutions: Facilitates staff and administration communications across campuses with reliable and clear audio quality.
• Remote Work Setups: Ideal for home offices or remote work situations where reliable, secure communication is critical.
• Construction Sites: Offers durable handsets with IP54 dust and water resistance, suitable for rugged environments.

• High-performance SIP cordless phone system
• 2.4" 240 x 320 color screen with intuitive user interface
• Up to 20 simultaneous calls
• Up to 10 DECT cordless handsets
• Up to 10 VoIP accounts
• Support Opus audio codec
• Up to 30-hour talk time (in ideal conditions)
• Up to 400-hour standby time (in ideal conditions)
• Quick charging: 10-min charge time for 2-hour talk time
• TLS and SRTP security encryption
• Noise Reduction System
• Headset connection via 3.5 mm jack
• Charger wall mountable

Phone

• Up to 20 simultaneous calls
• Up to 10 handsets
• Up to 10 VoIP accounts
• Up to 2 simultaneous calls per handset
• Up to 6 repeaters per base station (RT30)
• Handset selection for receiving call
• Handset and number selection for placing call
• Paging, intercom, auto answer, dial plan
• Call hold, call transfer, 3-way conference
• Switching between calls
• Call waiting, mute, silence, DND
• Caller ID with name and number
• Anonymous call/Anonymous call rejection
• Call forward: Always/Busy/No Answer
• Speed dial/Voicemail/Redial
• Message Waiting Indication (MWI)
• Music on hold (server-based)
• Local phonebook for up to 1000 entries (stored in the base)
• Remote phonebook/LDAP/XML phonebook
• Phonebook search/import/export
• 100 call history per handset: All/Placed/Missed/ Received/Forward
• Direct IP call without SIP proxy
• Reset to factory, reboot
• Keypad lock, emergency call • Broadsoft directory, BroadSoft call log
• Broadworks feature key synchronization
• Shared Call Appearance (SCA)
• XML browser
• Action URI

Personalization

• 9 ringer melodies
• Screen saver
• Multilingual user interface

Management

• Auto-provision via TFTP/FTP/HTTP/HTTPS/RPS
• Auto-provision with PnP
• Handset upgrade: OTA (Over-The-Air)
• Configuration: browser/phone/auto-provision
• Trace package and system log export

Audio

• Full-duplex speakerphone
• Hearing Aid Compatibility (HAC) compliant
• Receiver volume control: 5 steps
• Ringer volume control: 5 steps+off
• Multiple advisory tones
• Acoustic warning for low battery status
• DTMF
• Wideband codec: Opus, AMR-WB (optional), G.722
• Narrowband codec: AMR-NB (optional), PCMU, PCMA, G.726, G.729, G.729A, iLBC
• VAD, CNG, AGC, PLC, AJB
• AEC (supported by W56H)
• Support VQ-RTCPXR (RFC6035), RTCP-XR

Network

• SIP v1 (RFC2543), v2 (RFC3261)
• SNTP/NTP
• VLAN (802.1Q and 802.1P)
• 802.1x, LLDP
• STUN Client (NAT Traversal)
• UDP/TCP/TLS
• IP assignment: Static/DHCP
• Support outbound proxy server backup

Security

• Open VPN
• Transport Layer Security (TLS)
• HTTPS (server/client), SRTP (RFC3711)
• Digest authentication
• Secure configuration file via AES encryption
• Support SHA256/SHA512/SHA384
• Three-level configuration mode: Admin/Var/User

DECT

• Frequency bands: 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US), 1902 – 1906 MHz (TH), 1910 – 1920 MHz (BR)
• DECT Standards: CAT-iq2.0

Interface

• 1 x RJ45 10/100M Ethernet port
• Power over Ethernet (IEEE 802.3af), Class 1
• Headset jack (3.5 mm)

Physical

• Indoor Range: 50m (in ideal conditions)
• Outdoor Range: 300m (in ideal conditions)
• Standby Time: 400 hours (in ideal conditions)
• Talk Time: 30 hours
• 2.4’’ 240x320 pixels color display
• Desktop or wall mountable
• LCD backlit, key backlit
• Energy-saving ECO mode/ECO Mode+
• 12 key numerical keypad, 5 navigation keys, 2 softkeys, 6 function keys, 6 shortcut keys
• Three LED indicators on W70B:
• 1 x Registration LED
• 1 x Network Status LED
• 1 x Power Indicator LED
• External Yealink AC adapter: AC 100-240V Input and DC 5V/600mA Output
• Color: Handset: Alabaster Silver; Base: Classic Grey
• Handset size: 175mm x 53mm x 20.3mm
• Base station size: 130mm x 100mm x 25.1mm
• Operating humidity: 10 ~ 95%
• Operating temperature: 0~+40°C (+32~104°F)

Package

• Package contents:
• W56H Handset
• W70B Base Station
• Base Stand
• USB Charger Cradle
• Two Power Adapters
• Ethernet Cable
• Belt Clip
• Rechargeable Battery
• Quick Start Guide
• Qty/CNT: 10 PCS
• Giftbox size: 205mm × 196mm × 95mm
• Carton meas: 495mm × 406mm × 223mm
• N.W: 7.5 kg
• G.W: 8.3 kg
